600 LED Electromagnetic Lock
Supplier
Category
Security equipment
Color
Family
Door entry access control
Brand
WatchNET
ADD TO QUOTATION
Specifications
Description
The 600 series electromagnetic locks are renown with its excellent holding force and the remarkable features. The series compliance to CE and PSB Test are manufactured under the highest quality control to achieve the commitment to customer who always satisfied with maximum quality and reliability Features: Dual Voltage Selectable (12 VDC or 24 VDC) Low Current Consumption Reliable Holding Force Hall Effect Sensor Monitoring Output Green/Red LED Indication for EM Lock Status Built-in Mag.Contact for Door Status Monitoring Durable and Silence Operation Cosmeticize Anodized Aluminum Casing Surge & Spike Protection PCB Anti-Tamper Jam Nuts Full Range of Optional Brackets Anti Residual Magnetism Kick Off Button www.watchnetaccess.com 600 LED Electromagnetic Lock Division of WatchNET Inc. Specifications: Voltage Input: 12 VDC / 24 VDC Current Draw: 12V / 500mA ; 24V / 250mA (±5%) Holding Force: Up to 600 lbs (272 kg) Hall Effect Contact: SPDT rated 2A at 24 VDC Magnetic Contact Rating: 28 VDC, 0.5A, 10W Anti-Rust Surface Treatment: Blue Zinc Plating Operating Temperature: 0~55° C (32~131° F) Operating Humidity: 0~95% (non condensing) Dimensions: Magnet - (L)250x(W)42x(T)25 mm Armature - (L)180x(W)38x(T)11 mm
See More See less
Notes
Download the technical sheet to Set the jumper position according to the power
Specifications
  • Weight
    1.1 KG
  • Length
    250 mm
  • Diameter
    25 mm
  • Unit
    unit
  • Width
    42 mm
  • Material
    Blue Zinc Plating
